產品介紹

壓濾機系列

FILTER PRESS SERIES

壓濾機概述、產品介紹、型號說明

概述   overview

壓濾機分為板框式壓濾機和廂式壓濾機，它是一種間歇性的加壓過濾設備，用于各種懸浮液的固液分離。它是依靠壓緊裝置將濾板壓緊，再將懸浮液用進料泵壓入濾室，通過濾布來達到將固體顆粒和液體物料分離的目的。整機結構簡單，分離效果好，使用方便，使用范圍廣，廣泛用于礦山、冶金、石油、化工、醫藥、紡織、印染、造紙、食品、酒精、無機鹽、洗煤以及污水處理等領域。

Filter presses can be divided into plate and frame type and chamber type. It is one kind of intermittent filter equipment. It is used for solid-liquid separation of various suspending liquid. Filter plates are pressed by pressing devices, and then suspension is pumped into the filter chamber. Solid particles and liquid is separated through filter cloth. The products are simple in structure but good in separating effects, convenient in use, and widely used in mining, metallurgy, petroleum, chemical, medicine, textile, printing and dyeing, paper making, foodstuff, alcohol, inorganic salt, coal washing, dyestuff and sewage treatment industries.

產品介紹   product introduction

我公司提供各種型號的廂式和板框式機械壓濾機、液壓壓濾機、隔膜壓濾機、快開式壓濾機、全自動壓濾機以及壓濾機配件，質量可靠，規格齊全。

1、         濾板規格有：320型、450型、630型、800型、870型、1000型、1250型、1500型、2000型等。

2、         過濾面積最大到2000㎡。

3、         濾板材質分鑄鐵、不銹鋼、增強聚丙烯，玻纖聚丙烯等。

4、         液流形式有明流、暗流、可洗、不可洗、中進料、角進料等多種形式。

5、         濾板壓緊方式有：手動螺旋壓緊、電動機械壓緊和液壓油缸壓緊。對于特殊要求的壓濾機可另行商定解決。

Our company supplies various types of recessed plate and plate-frame mechanical filter press, hydraulic filter press, membrane filter press, quick open filter press, full-automatic filter press and filter press spare parts.

1、         Filter plate specification include: 320mm, 450mm, 630mm, 800mm, 870mm, 1000mm, 1250mm, 1500mm and 2000mm etc.

2、         Filtration area up to 2000㎡

3、         Filter plate materials: cast iron, stainless steel, reinforced polypropylene, glass fiber polypropylene etc.

4、         Flow forms: open flow, close flow, washable, non-washable, middle feeding and corner feeding etc.

5、         Filter plate pressing modes: manual screw pressing, electric mechanic pressing and hydraulic cylinder pressing, Special filter press can be made on request.

加型號說明圖

結構與工作原理   structure and operating principle

1、         壓濾機由機架、濾板、壓緊系統（手動、機械、液壓三種形式）和電氣控制柜組成。

2、         機架部分起支撐壓緊裝置和濾板的作用，由機座、壓緊板、止推板和主梁組成。

3、         濾板安裝在壓緊板和止推板之間的主梁上，中間裝有濾布。

4、         工作時，由壓緊裝置（油缸活塞桿或絲桿）推動壓緊板，將位于壓緊板和止推板之間的濾板和濾布壓緊，被壓緊的濾板與濾板之間就形成了濾室，由料泵壓入的物料從止推板進料孔進入各個濾室，固體顆粒被截留在濾室內，并形成濾餅，液體則透過濾餅和濾布由出液孔排出機體外。若需要對濾餅進行洗滌，可用尾板上的洗液口通入洗滌水對濾餅進行洗滌。若需將濾餅吹干，可由洗液口通入壓縮空氣，將濾餅吹干。

5、         板框式壓濾機架的結構與廂式壓濾機相同，只是過濾部分是一板一框和濾布組成，板框空間是濾室。

6、         壓濾機的液流形式分為明流、暗流。明流是指濾液從每塊濾板的出液孔直接排出機外；暗流是指各塊濾板的濾液匯合起來由出液孔道排出機外。

1、         Filter press consists of frame, filter plate, pressing system (manual, mechanical or hydraulic) and electric control cabinet.

2、         Frame consists of base, pushing plate, tail plate and beam and frame supports the pressing device and filter plates.

3、         Filter plates are installed on the beam between tail plate and push plate, with filter cloth sandwiched in them.

4、         In operation, the pressing device (cylinder piston rod or screw) drives the push plate to press the filter plate and filter cloth between push plate and tail plate. Filter chamber are formed between pressed filter plates and materials get into the filter chambers through the feeding inlet of tail plate. Solid particles are remained in filter chambers forming into cakes, while liquid is discharged out of the machine through press cake and filter cloth. To wash the press cakes, washing water can be introduced through the washing inlet of the tail plate. In similar manner, drying the filter cakes with compressed air going into the washing inlect.

5、         Structure of plate-frame type and chamber type filter press is the same. Except the filtering part that consists of one plate, one frame and filter cloth, with filter chamber between plate and frame.

Liquid stream of filter press can be divided into open stream and close stream. Open flow refers to that the filtrate is discharge directly from the outlet of filter plate; Close flow refers to that the filtrate is collected from vario
